Specifications

• Dimensions

  add remove
  • Length:
    2265 mm
  • Seat height, laden (low seat position):
    31.1 in. (789 mm)
  • Seat height, laden (high seat position):
    32 in. (814 mm)
  • Seat height, unladen (low seat position):
    33.4 in. (850 mm)
  • Seat height, unladen (high seat position):
    34.4 in. (875 mm)
  • Ground clearance:
    210 mm
  • Rake:
    25
  • Trail:
    108 mm
  • Wheelbase:
    1580 mm
  • Tyres, front specifications:
    120/70R19 60V
  • Tyres, rear specifications:
    170/60R17 72V
  • Fuel capacity:
    21.2 l
  • Oil capacity:
    4.3 l
  • Weight, as shipped:
    229 kg
  • Weight, in running order:
    244.94 kg
  • Tyre, type:
    Michelin®Scorcher®“Adventure”, Radial
• Engine

  add remove
  • Engine:
    Revolution® Max 1250
  • Bore:
    105 mm
  • Stroke:
    72 mm
  • Displacement:
    1252 cm³
  • Compression ratio:
    13.0:1
  • Fuel system:
    Electronic Sequential Port Fuel Injection (ESPFI)
  • Exhaust:
    2-into-1-into-1; catalyst in header
• Performance

  add remove
  • Engine torque testing method:
    J1349
  • Engine torque:
    127 Nm
  • Engine torque (RPM):
    6750
  • Lean angle, right (deg.):
    42
  • Lean angle, left (deg.):
    42
  • Fuel economy testing method:
    Estimated City/Hwy
  • Fuel economy:
    5.1 l/100 km
• Drivetrain

  add remove
  • Primary drive:
    Gear, 49/89 ratio
  • Gear ratios (overall) 1st:
    13.11
  • Gear ratios (overall) 2nd:
    9.687
  • Gear ratios (overall) 3rd:
    7.509
  • Gear ratios (overall) 4th:
    6.057
  • Gear ratios (overall) 5th:
    5.08
  • Gear Ratios (overall) 6th:
    4.436
• Chassis

  add remove
  • Wheels, optional style type:
    Annodized aluminum tubeless laced
  • Wheels, front type:
    Aluminum cast, satin black
  • Wheels, rear type:
    Aluminum cast, satin black
  • Brakes, caliper type:
    Front: radially mounted, monoblock, 4-piston caliper; Rear: floating, single piston caliper
• Electric

  add remove
  • Lights (as per country regulation), indicator:
    LED Bullet Turn Signals
  • Gauges:
    6.8 inch viewable area TFT display with speedometer, gear, odometer, fuel level, clock, trip, low temp alert, side stand down alert, TIP over alert, cruise, range and tachometer indication BT capable - phone pairing to access phone calls, music, navigatio
• Infotainment

  add remove
  • Type:
    Color TFT w/ Touch
  • Headset specifications (if equipped):
    Bluetooth
  • Languages:
    Arabic, Chinese (Simplified/Traditional), Czech, Danish, Dutch, English (default), Finnish, French (Canada/France), German, Greek, Hungarian, Italian, Japanese, Korean, Norwegian, Polish, Portuguese (Portugal/Brazil), Indonesian, Russian, Slovak, Spanish
  • Hands-free mobile phone — via Bluetooth:
    Standard
  • Voice Recognition Languages: Phone functions only:
    Phone dependent
  • Voice Recognition Languages: Tuner / Media / Navigation:
    Phone dependent
  • Text-to-Speech (TTS) languages:
    Phone dependent
  • Rider / passenger intercom:
    Headset function only
  • Vehicle information screen:
    Engine temp, Battery Voltage
  • USB:
    Charging and Instrument update, USB-C, 5V, 3A
  • Bluetooth:
    Phone/Media Supported
